Compact 5kWh Wall-Mounted LiFePO4 Home Battery Storage - China Factory Suppliers with 6000+ Cycles
1. High Performance and Intelligent Management
The HZEB-LCT-5 delivers reliable energy storage with a compact design. Its intelligent BMS supports remote fault diagnosis, OCV algorithm calibration for accurate SOC, and over-the-air upgrades. With a cycle life of over 6000 cycles and a wide voltage range of 44.8V–57.6V, it ensures long-term stability and smart energy management for modern homes.
2. Safe, Reliable and Adaptable
Equipped with LiFePO4 battery cells certified to UN38.3, MSDS, IEC62619, and CE-EMC standards, the HZEB-LCT-5 prioritizes safety. Its IP54 rating provides dust and water protection, while the modular design allows parallel connection of up to 15 units. Installation is flexible with wall-mounted setup, making it ideal for residential energy storage systems.
3. Environmental Specifications and Easy Installation
Designed to operate in diverse conditions, the HZEB-LCT-5 supports charging from 0°C to 55°C and discharging from -20°C to 55°C. It functions at altitudes up to 2000m with humidity tolerance ≤90%. With compact dimensions (400×160×700mm) and a weight of 59kg, it offers easy handling and space-saving installation for home energy independence.
Frequently Asked Questions
Q1 What is the cycle life of the HZEB-LCT-5 battery?
The HZEB-LCT-5 features a cycle life of over 6,000 cycles, ensuring long-term reliable performance and reducing the need for frequent battery replacement in residential energy storage applications.
Q2 What certifications does the HZEB-LCT-5 hold?
The HZEB-LCT-5 LiFePO4 battery cells are certified to UN38.3, MSDS, IEC62619, and CE-EMC standards, guaranteeing compliance with international safety and quality requirements.
Q3 How many HZEB-LCT-5 units can be connected in parallel?
The modular design of the HZEB-LCT-5 supports parallel connection of up to 15 units, allowing homeowners to scale their energy storage capacity to meet growing energy demands.
Q4 What temperature range does the HZEB-LCT-5 operate in?
The HZEB-LCT-5 supports charging between 0°C and 55°C, and discharging between -20°C and 55°C, making it suitable for a wide range of climatic environments and seasonal conditions.
Q5 What is the IP rating of the HZEB-LCT-5 and what does it protect against?
The HZEB-LCT-5 carries an IP54 rating, which provides reliable protection against dust ingress and water splashing from any direction, ensuring safe operation in typical residential indoor and outdoor environments.
Q6 Does the HZEB-LCT-5 BMS support remote management?
Yes. The intelligent BMS of the HZEB-LCT-5 supports remote fault diagnosis, OCV algorithm calibration for accurate state-of-charge (SOC) readings, and over-the-air (OTA) firmware upgrades, enabling convenient and proactive system management.
